Circulation Heaters
COMIND® flow heaters consist of a carbon steel or stainless steel chamber, inside which a flange or thread type resistance is mounted, which allows the temperature of a liquid or gas to be increased only for the time in which it is cooled. It takes a long time to pass through the heater, with an inlet and outlet chamber that allows the flow of whatever you want to heat to pass through. It allows the thinning of high density oils to allow easy flow through a pump, heating oil (for example petroleum), increasing the temperature of different gases or air, heating water to be stored in reserve tanks, thermal transfer, washing and rinsing associated with different detergents.
catalog and resources
design and construction
(Check out COMIND CONNECT panel options).
HOW TO REQUEST A QUOTE FOR YOUR COMIND® TANKLESS HEATER?
To request a quote for your COMIND® tankless heater, you must provide your vendor with the heater’s power and voltage, its intended use, the required solution heating time, general measurements, and the dimensions of the inlets and outlets
| OPTIONS | SPECIFICATIONS |
|---|---|
| power and voltage | According to customer requirements. |
| Terminal junction box | For general purposes or explosion-proof systems. |
| Camera material | Carbon steel or stainless steel |
| Thermal insulation | Mineral wool or ceramic fiber |
| Temperature controls | Thermostat with various settings |
| Electrical systems | Contactors or solid-state relays |
| Flange measurement | 3”, 4”, 5”, 6”, 8”, 10”,12” y 14” or as required (150lb o 300lb) |
| OPTIONS | SPECIFICATIONS | |
|---|---|---|
| Thermal transfer of oils | Mainly used for molds or platforms that require thermal transfer to a specific product. | |
| Oil heating | Mainly used for preheating of petroleum, which is supplied to their respective burners. | |
| Water | Heating of water to be stored in reserve tanks for use in various industrial processes, washing systems, and rinses with different detergents.. | |
| Air, Gases |
|
|
| Other | Thinning very viscous oil so that it can flow easily through a pump. |
